Metal CNC Machining

Sanluo Precision is a professional manufacturer and supplier of Metal CNC Machining in China. Over the past fifteen years, we have accumulated profound technical strength in the field of CNC Machining and established a complete process flow system. We are not only capable of processing conventional metal materials, but also can provide high-precision processing services for various non-ferrous metals, ferrous metals, and rare metals for industries such as healthcare, semiconductors, and research laboratories. We can also offer customized Metal CNC Machining services according to customer needs, supporting the customization of complex and difficult parts.

Send Inquiry

Product Description

Metal processing expertise

Sanluo Precision Company has extensive practical experience and possesses mature Metal CNC Machining technology. It is proficient in processing various materials and has expertise in precision machining of aluminum alloys and copper alloys. It conducts appropriate aging treatment on various types of aluminum alloys such as 2 series, 6 series, and 7 series to achieve the precision target for controlling deformation. The factory makes full use of the high strength, superior machinability, and super hardness characteristics of aluminum alloys. For copper alloy processing, it can machine alloy materials such as H62 brass, T2 copper, and C17200 beryllium copper. By adjusting cutting parameters according to different alloy characteristics, it can achieve better surface roughness and dimensional stability. Additionally, we have our own methods for processing high-hardness materials. It can machine stainless steel 17-4PH (HRC38-42), tool steel SKD11 (HRC58-62), and steel with hardness above HRC50. Using hard alloy tools and slow feed, small cutting depth, etc., the entire processing process is stable and of high precision. For ultra-hard materials, Metal CNC Machining can also use special processing techniques such as electrical discharge machining and wire cutting.

Workstation Accuracy

dimensional accuracy	L（X）	W（Y）	H（Z）	SH	GD
unit:±/mm	0.005	0.002	0.001	0.005	0.008
Geometric accuracy	flatness	parallelism	perpendicularity	roughness	Position tolerance
unit:±/mm	0.002	0.003	0.005	Ra0.8	0.01
production capacity	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs
production cycle	3-20 days	3-20 days	3-20 days	3-20 days	3-20 days

The configured testing instruments and measuring tools include: CMM (three-coordinate measuring machine), image analyzer, projector, laser diameter gauge, laser interferometer, roughness gauge, roundness gauge, tool microscope, stereomicroscope, micrometer, thread gauge, vernier caliper, micrometer scale, ten-thousandth micrometer, electronic height gauge, caliper, gauge blocks, hardness tester, thread gauge.

Batch supply capability

As a professional Metal CNC Machining manufacturer, Sanluo Precision Factory is equipped with complete surface treatment facilities. We offer a variety of anti-rust and anti-corrosion treatment services. For steel parts, we can blacken, phosphatize, and galvanize; for aluminum parts, we can anodize, hard anodize, and chemical nickel plating; for stainless steel parts, we can passivate; for copper parts, we can plate silver and gold. We have modern automated production lines with advanced equipment such as mechanical hands, conveyor belts, and automatic cleaning machines, achieving efficient and less-person-intensive production methods. The monthly production capacity is 100,000 pieces, ensuring the delivery of medium to large-scale orders. Currently, we have provided customized metal working services to many Fortune 500 companies and established long-term and stable strategic manufacturing partnerships. We supply over 2 million parts annually.

Equipment Technical Parameters

Parameter Category	Technical Specifications
Equipment Model	JDGR300T 4-Axis High-SpeedMachining Center
Core Positioning	Designed for micron-level ultra-high-precision machining; suitable for precision medical components.
CNC System	Features the JD50 CNC system, independently developed by Jingdiao, with a motion control resolution of 10 nm.
Key Precision	Achieves stable 0.1μm feed rates and 1μm cutting depths, yielding nanoscale surface finishes.
Spindle System	Equipped as standard with a high-speed, high-precision electric spindle delivering 21.5 Nm of torque.
Tool Magazine System	Features a chain-type automatic tool changer.
Core Advantages	Incorporates on-machine measurement technology to automatically detect and compensate for errors, ensuring high yield rates in batch production.
Typical Applications	Ideal for medical metal CNC machining applications—such as surgical instrument components and orthopedic implants—that demand stringent dimensional accuracy and surface quality.

Parameter Category	Technical Specifications
Equipment Model	SUPER QUADREX 200
Core Positioning	4-Axis Controlled Multi-Tasking CNC Lathe—Ideal for High-Volume Production
Processing Capability	Max. Machining Diameter: 350 mm \| Max. Machining Length: 610 mm
Turret System	Dual Turret Configuration (Upper & Lower): Enables Simultaneous Machining Operations \| Turret Type: 8-Station Drum Turret + 12-Station Drum Turret
Spindle System	Max. Spindle Speed: 5000 rpm \| Max. Milling Spindle Speed: 4500 rpm (Optional: 6000 rpm)
Core Functions	Supports Simultaneous Machining of OD/ID Features; Integrated Milling Capabilities Enable Operations Such as Drilling and Tapping
Core Advantages	Significantly Reduces Machining Time and Lead Times Through Synchronous Processing and Multi-Tasking Functionality
Typical Applications	Precision Metal CNC Machining of Components and Parts
