Precision Laser Welding Processing

Sanluo Precision is a professional manufacturer and supplier of precision laser welding processing in China, with more than 10 sets of various laser welding equipment, the minimum spot diameter is 0.02mm, the thinnest welding wall thickness is 0.01mm, providing customers with high-quality laser beam machining services and supporting the customization of complex and difficult parts. It covers the fields of medical devices, electronic components, precision mechanical components, etc., and has developed customized laser welding methods for the medical device field, realizing precise welding between micro parts, dissimilar materials and thin-walled structures, covering the process and technical standard requirements of precision laser welding processing in various industries.

Send Inquiry

Product Description

Rich Application Cases

Welding of battery tabs for electronic devices, aluminum-nickel welding, copper-nickel welding, solder joint diameter from 0.02mm to 1mm, tensile strength greater than 50N; hermetic welding of sensor housings, weld width from 0.02mm to 0.5mm, air tightness less than 10⁻⁹Pa·m³/s. Welding of thin-walled bellows for precision machinery, wall thickness from 0.01mm to 0.3mm, no weld penetration; welding of titanium alloy vacuum chambers, dense welds without blowholes. Laser welding of gear shafts for auto parts with a penetration depth of 0.03-0.5mm and high torsional strength; beautiful and corrosion-resistant welds for exhaust pipe welding. Welding of stainless steel catheters for medical devices, wall thickness from 0.01mm to 0.2mm, smooth welds without cracks. Sanluo Precision provides professional customized precision laser welding processing services to the whole world.

Station Accuracy

Minimum welding depth	Minimum welding diameter	Minimum welding wall thickness	Minimal beam diameter	Is it gas protection	Weldable materials
0.002mm	0.01mm	0.01mm	0.03mm	yes	Stainless steel, copper, aluminum
Production capacity	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs
Production cycle	3-20 days	3-20 days	3-20 days	3-20 days	3-20 days

Welding Process Technology

Sanluo Precision is a professional precision laser welding processing plant, which attaches great importance to process control. Matching of laser power, welding speed, defocus amount and protective gas flow. Heat input control prevents thermal deformation by adjusting pulse energy and frequency. The gap is controlled below 0.1mm to ensure welding quality. Protective gas: argon prevents oxidation, the weld is silvery white; nitrogen is low cost, suitable for stainless steel; helium has fast heat transfer and large penetration depth. Oil removal, rust removal and oxide skin removal before welding to ensure reliability. Post-weld inspection: X-ray flaw detection, ultrasonic flaw detection, air tightness test, tensile strength test.

Technical Parameters of Precision Laser Welding Processing Equipment

Parameter Category	Parameter Details
Equipment model	Hanjang W series (taking HWC-500 as an example)
Core positioning	General precision welding with high stability
Number of axes	/
Laser type	Fiber laser
Laser wavelength	1080±10nm
Working mode	Continuous/pulse/modulation
Output average power	500W (HWC-500 model)
Beam quality (M²)	2.5 (HWC-500 model)
Power stability	≤3%
Core advantages	Built-in welding waveform generation system, supporting IO waveform calling or external analog quantity; pure fiber structure, maintenance-free
Typical applications	Precision laser welding processing for medical equipment electronics, mobile communication, electronic components, precision parts, etc

Parameter Category	Parameter Details
Equipment model	FLW 400
Core positioning	Flexible laser welding of symmetrical rotary parts
Laser	Adopt Trumpf fixed disc laser
Workbench	Modular rotary workbench
Core advantages	Supports independent stations to complete assembly-preheating-welding in parallel; improves weld strength through the balance technology of deep penetration welding and precision welding
Typical applications	Precision laser welding processing for symmetrical rotary parts in the fields of semiconductors, precision manufacturing, etc
