Micro Swiss Machining

Sanluo Precision is a leading manufacturer and supplier of micro swiss machining in China, with more than 20 advanced Swiss-type sliding head lathes, providing customers with efficient micro CNC machining services. We offer professional customized micro CNC machining services for precision medical, electronic connectors, watch accessories, aerospace parts and other industries, supporting the customization of complex and difficult parts. We realize high-precision mass manufacturing of slender shaft parts and complex rotating parts, fully meeting the stringent requirements of high-end manufacturing for micro swiss machining.

Send Inquiry

Product Description

Swiss Machining Technology

Micro swiss machining, also known as sliding head turning, uses a guide bush to support the bar, and the cutter processes close to the guide bush with a short overhang length and good rigidity. The machining diameter range is φ0.05-10mm, the maximum length is up to 300mm, and the length-diameter ratio can reach 100:1. Machining accuracy: diameter ±0.005mm, length ±0.01mm, concentricity 0.01mm, surface Ra0.4-0.8μm. Multi-axis simultaneous compound machining, turning, milling, drilling and tapping are completed at one time, with a single part processing time of a few seconds to 5 minutes, and automatic feeding without manual intervention.

Station Accuracy

Dimensional accuracy	OD	ID	T（C）	DP	DA
unit:±/mm	0.001	0.001	0.001	0.001	0.0001
Geometric accuracy	Roundness	Coaxiality	Straightness	Cylindricity	Circular runout
unit:±/mm	0.001	0.002	0.001	0.002	0.001
Production capacity	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs
Production cycle	3-20 days	3-20 days	3-20 days	3-20 days	3-20 days

Obvious Machining Advantages

Sanluo Precision's processing plant has obvious advantages in micro swiss machining: slender part machining (guide bush support with an overhang length of only 5-10mm, length-diameter ratio >50 without vibration, concentricity 0.01mm), complex parts (compound turning, milling, drilling and tapping, eccentric holes, transverse holes, plane grooves and threads completed at one time), stable accuracy (guide bush positioning, machining accuracy not affected by bar runout, good batch consistency with Cpk≥1.67), high efficiency (completed in one clamping without secondary processing, short single part time suitable for mass production), material utilization rate (automatic bar feeding with short remaining material head, material utilization rate >95%), unmanned operation (automatic feeding, automatic chip removal, tool life monitoring, continuous production for 8-12 hours).

Typical Part Machining

As a professional manufacturer of micro swiss machining, Sanluo Precision's products have a wide range of applications: medical equipment (bone nails with a diameter of φ2-5mm and a length of 20-100mm, self-tapping guide tip with thread M2-M5; dental implants with a diameter of φ3.5-5mm, Morse taper and sandblasted multi-start thread surface), electronic connectors (pins with a diameter of φ0.5-2mm and a length of 5-30mm, complex features such as chamfers, grooves and steps; USB interface shell with an outer diameter of φ4mm and a wall thickness of 0.3mm, open window plane), watch accessories (watch shafts with a diameter of φ0.8-2mm and a length of 10-20mm, step shafts and eccentric shafts with IT6 precision grade; gear shafts with a module of 0.15-0.3mm and 10-30 teeth, gear and shaft integrated machining), aerospace parts (hydraulic joints with a diameter of φ3-10mm, internal and external threads with sealing grooves and good air tightness; sensor shells with thin walls of φ5mm and a wall thickness of 0.5mm, dimensional accuracy ±0.01mm). We are equipped with equipment of brands such as Tsugami, Citizen, Star, Biglia, with a monthly production capacity of 800,000 pieces, first article inspection + SPC monitoring with a defective rate of <0.2%, regular delivery time of 3-5 days and 48 hours for urgent orders. We have provided customized micro CNC machining services for enterprises such as Medtronic, Stryker, TE Connectivity, etc., with an annual output of 2 million pieces and a customer satisfaction rate of 98%.

Technical Parameters of Micro Swiss Machining Equipment

Parameter Category	Parameter Details
Equipment model	SwissNano 7
Core Positioning	Ultra-high precision small workpiece machining
Number of Axes	Six-axis motion structure
Design Features	The back spindle installed on three linear axes makes the machine tool extremely easy to use
Application Fields	Medical, micromechanical, electronic and other industries with ultra-high precision requirements
Typical Applications	precision micro swiss machining parts, etc

Parameter Category	Parameter Details
Equipment model	Schaublin 136CNC
Core Positioning	Mass machining of precision shaft parts and small shell parts
Number of Axes	5-axis
Key Accuracy	Able to achieve 0.2μm roundness cutting, surface roughness up to Ra 0.05μm
Core Configuration	Machine tool temperature control system; adopt new Sauter turret with tool seat positioning accuracy ±1μm; precision C-axis accuracy up to 2 arc seconds
Machining Capacity	Able to perform hard material turning of HRC65 and titanium alloy machining
Core Advantages	High machining accuracy and excellent precision consistency of parts
Typical Applications	precision micro swiss machining parts, etc
