Sanluo Precision’s facing machining is a process for processing the end plane of parts. Face turning is clamped by three-jaw chuck and processed by face turning tool, with turning speed 500-2000rpm, feed rate 0.1-0.5mm/r, cutting depth 0.5-3mm; rough turning leaves allowance 0.5mm, finish turning single side 0.1-0.2mm. Strict quality control: flatness detection (height difference measured by dial gauge with flat plate, CMM accuracy 0.003mm, large plane measured by laser interferometer); perpendicularity (right-angle ruler against end face outer circle, gap measured by feeler gauge, angle deviation measured by CMM); parallelism detection (dial gauge at one end, rotate workpiece to measure runout); roughness meter to measure Ra value (≥5 detection points to take average); visual inspection for tool marks, scratches, burrs; process guarantee (sharp tools, reasonable parameters, sufficient cooling, rigid clamping).
|
Dimensional accuracy |
OD |
ID |
T（C） |
DP |
SW |
|
unit:±/mm |
0.002 |
0.005 |
0.001 |
0.002 |
0.002 |
|
Geometric accuracy |
Roundness |
Coaxiality |
Straightness |
Cylindricity |
Symmetry |
|
unit:±/mm |
0.002 |
0.005 |
0.001 |
0.002 |
0.002 |
|
Production capacity |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
|
Production cycle |
3-20 days |
3-20 days |
3-20 days |
3-20 days |
3-20 days |
As a professional facing machining processing plant, Sanluo Precision has a wide range of applications: machinery manufacturing (flange end face φ100-500mm flatness 0.03mm for sealing fit, gear end face parallelism 0.02mm), mold processing (cavity end face flatness 0.01mm, guide pillar guide sleeve perpendicularity 0.01mm), auto parts (brake disc end face flatness 0.05mm, flywheel end face parallelism 0.03mm), precision instruments (optical platform flatness 0.005mm surface Ra0.4μm), pump and valve parts (sealing surface flatness 0.02mm no leakage), hydraulic and pneumatic (cylinder end cover/oil pump end face parallelism 0.02-0.03mm). We have provided customized turning machining services for XCMG, Sany, Weichai, Yuchai, Gree and other enterprises, with an annual processing of 2 million pieces and a flatness pass rate of 99.5%.
|
Parameter Category |
Parameter Details |
|
Equipment model |
SGR-700SP |
|
Core Positioning |
Ultra-precision face grinding |
|
Key Accuracy |
Min. infeed 0.001 mm; grinding wheel spindle infeed speed 0.001–1.500 mm/min |
|
Chuck System |
Permanent electromagnetic chuck (power off during adsorption, no thermal effect), diameter φ700 mm |
|
Patented Technology |
Automatic grinding wheel grinding pressure adjustment mechanism (avoid excessive pressure); 3-point support fixed type surface tilt adjustment mechanism (sub-micron level adjustment) |
|
Processing Capacity |
Corresponding to max. workpiece size: 170mm(H) × 700mm(φ) × 300kg |
|
Automation and Environmental Protection |
Newly developed automatic grinding sizing device; IE3 standard motor, significant energy-saving effect |
|
Typical Applications |
precision facing machining parts, etc |
|
Parameter Category |
Parameter Details |
|
Equipment model |
KG-500 |
|
Core Positioning |
3-axis compound grinding machine (internal and external circle and face) |
|
CNC Axis |
3-axis |
|
CNC System |
FANUC controller |
|
Processing Capacity |
Grinding diameter range ø4～ø320 mm; max. grinding depth 200 mm |
|
Structural Features |
Dual grinding wheel spindle structure; bed made of FC30 high-grade cast iron, tempered and stress relieved; X, Z axis adopt linear guide rail and ball screw |
|
Stroke (X/Y/Z) |
390 mm / 350+200 mm / 350+200 mm |
|
Typical Applications |
precision facing machining parts, etc |
