Medical-grade CNC Machining

Sanluo Precision is a professional manufacturer and supplier of medical-grade CNC machining in China. We have the capability to process complex parts, with a dimensional tolerance of ±0.001mm and a surface roughness of Ra 0.05μm. We have strong technical strength in CNC machining and perfectly match the advanced manufacturing technology with the requirements of CNC processing for medical device parts and medical equipment parts. We provide professional customized services for customers and support the customization of complex and difficult parts.

Send Inquiry

Product Description

Advanced processing equipment

Sanluo Precision, as a professional manufacturer of medical-grade CNC machining, is equipped with advanced processing equipment, including an automatic loading and unloading system, an online inspection system, and a tool wear monitoring system, etc. This enables it to achieve less-personalized and intelligent manufacturing. The modularized workholding fixtures used in the workshop are designed to allow for setup changes within 30 minutes, which can meet the needs of multi-variety and small-batch production. The processing plant has introduced international advanced equipment and continuously learns and introduces advanced manufacturing processes from around the world. The technical support provided to customers is 24-hour uninterrupted. Responses to customers' requests are made within 12 hours, and answers to technical problems encountered by customers are provided within 24 hours. Relying on its strong manufacturing capabilities, it provides high-quality CNC machining services.

Workstation Accuracy

dimensional accuracy	OD	ID	T（C）	DP	R
unit:±/mm	0.002	0.003	0.005	0.005	0.005
Geometric accuracy	roundness	coaxiality	straightness	cylindricity	profile tolerance
unit:±/mm	0.001	0.004	0.002	0.003	0.002
production capacity	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs
production cycle	3-20 days	3-20 days	3-20 days	3-20 days	3-20 days

Quality Assurance Capability

Our company's medical-grade CNC machining has a reasonable and standardized quality control system, which is scientific and rigorous. A strict three-check system is implemented, namely self-inspection by the operator, patrol inspection by the dedicated inspector, and final inspection by the quality department. The company is equipped with coordinate measuring machines, projectors, micrometers, vernier calipers, height gauges, roughness meters, hardness testers, etc. for testing. The critical dimensions CMK are ≥ 1.67. Quality tools such as APQP (Product Quality Pre-Planning), FMEA (Failure Mode Analysis), MSA (Measurement System Analysis), SPC (Statistical Process Control), and PPAP (Production Part Approval Process) are adopted to ensure the stability of part quality. The first-piece inspection → small-batch trial production → mass production process quality tracking.

Compliance Assurance

Sanluo Precision factory strictly follows the standards set by the World Health Organization for medical-grade CNC machining. It can also follow the standards specified by the customers. We strive to learn and understand the regulations of various countries and regions. For example, the regulations of the United States include FDA 21 CFR Part 820 (quality system regulations), 510(k) pre-market notification, and PMA (pre-market approval). The EU medical device regulations, namely MDR 2017/745, CE certification and the preparation of technical documents. In China, there are YY/T0287 medical device quality management system, CFDA registration inspection.

Delivery and Service Assurance

Sanluo Precision can undertake customized medical-grade CNC machining services. The minimum order quantity (MOQ) is 1 piece. It supports multiple layers of protection such as degreasing, sterilization, disinfection, packaging, vacuum bags, cardboard boxes, and wooden boxes to ensure transportation safety. After-sales service: Quality issues are responded to within 48 hours, and technical support and improvement suggestions are provided. Sanluo Precision has directly or indirectly provided customized CNC machining services to world-renowned medical companies such as Johnson & Johnson, Medtronic, Stryker, and Siemens Healthcare. The customer satisfaction rate is over 95%.

Equipment Technical Parameters

Parameter Categories	Parameter Details
Equipment Model	INDEX TNL32 - Innovative Turning and Milling Combined Machine Center
Core Positioning	High-precision and high-complexity processing of medical screws
Spindle Speed	Maximum 8,000 rpm
Spindle Inner Diameter	32 mm
Maximum Z-axis Travel	305 mm
Multi-tasking Capability	Up to 3 cutting tools can be processed simultaneously.
Machine Structure	The thermally symmetrical machine structure helps maintain high precision over a long period.
Core Advantages	It can be easily switched between the sliding spindle box and the fixed spindle box operation modes, with high flexibility.
Typical Applications	High-end medical screws and other medical-grade CNC machining.

Parameter Categories	Parameter Details
Equipment Model	MIKRON UCP 600 Vario RTT
Core Positioning	High flexibility and precision solutions for multi-variety, small-batch production in the medical industry
Drive Method	4-axis high speed machining center with torque motor directly driving table
Spindle System	Spindle speed 20,000 r/min
Automation System	Integrated automatic tailstock system for workpiece clamping at both ends; workbench designed for 4-axis rotary parts
Key Functions	One-time clamping completes multi-surface processing, meeting the processing requirements of various medical instruments including bone plates, femoral files, artificial joints, etc.
Industry Positioning	One of the highest share models in the global medical industry
Typical Applications	precision medical-grade CNC machining parts, etc.
