Our CNC Swiss precision machining technology is the core process of sliding headstock machining. Machining principle: The bar is supported by a guide bushing, extending only 5—10mm, and the tool cuts in front of the guide bushing, with good rigidity and no vibration at the overhang end. Machining range: diameter φ0.5—32mm, mainly processing precision small parts of φ1—20mm, maximum length 300mm, length-diameter ratio up to 100:1, slender shafts without bending or deformation. Machining accuracy: diameter tolerance ±0.005mm, length tolerance ±0.01mm, concentricity 0.008mm, roundness 0.005mm, surface roughness Ra0.4-1.6μm. Multi-axis linkage: spindle, sub-spindle, opposing spindle, X, Y, Z, B, C multi-axis, up to 12-axis linkage, integrated turning, milling, drilling, tapping and boring completed in one clamping. Cooperation between main and sub-spindles: The main spindle processes the front end, and the sub-spindle takes over the material to process the rear end. Double-head processing improves efficiency by 50%, no secondary clamping error, and concentricity of both ends is 0.01mm.
|
Dimensional accuracy |
OD |
ID |
T（C） |
DP |
GD |
|
unit:±/mm |
0.002 |
0.002 |
0.005 |
0.002 |
0.001 |
|
Geometric accuracy |
Roundness |
Coaxiality |
Straightness |
Cylindricity |
Position tolerance |
|
unit:±/mm |
0.002 |
0.003 |
0.002 |
0.003 |
0.004 |
|
Production capacity |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
|
Production cycle |
3-20 days |
3-20 days |
3-20 days |
3-20 days |
3-20 days |
As a professional manufacturer of CNC Swiss precision machining, Sanluo Precision has strong mass production capacity. Equipment configuration: 30 high-end sliding headstock lathes such as Tsugami B20, Citizen A20, Star, Star SR20, Biglia DECO20, maximum spindle speed 12000r/min, guide bushing diameter φ1—32mm, 12 power tools. Production capacity scale: monthly output 600,000 pieces, daily output 20,000 pieces, meeting large-batch orders. Technical support: DFM analysis, optimizing part design, simplifying processing procedures, reducing manufacturing costs and improving yield. The company has directly or indirectly provided customized swiss machining services for internationally renowned enterprises such as Boeing, Medtronic, Zeiss, Corning, etc., with an annual output of 4 million high-precision parts and a qualification rate of 99.95%, leading the industry in accuracy.
|
Parameter Category |
Parameter Details |
|
Equipment model |
Swiss XT 32/9 |
|
Brand |
Tornos |
|
Core Positioning |
Multi-functional and high-performance complex part processing |
|
Number of Axes |
8/9 linear axes + 2 C-axes; optional plug-and-play B-axis |
|
Machining Capacity |
Maximum machining diameter 32 mm |
|
Tool System |
Up to 40 tools, including 18 power tool positions; 3 independent tool systems |
|
Special Processes |
Supports hobbing, polygon milling/whirling milling, internal and external whirling milling, deep hole drilling, etc |
|
Core Advantages |
Compact design, quick guide bushing conversion, maximum flexibility |
|
Typical Applications |
CNC Swiss precision machining for semiconductor, medical and dental, electronic parts, etc |
|
Parameter Category |
Parameter Details |
|
Equipment model |
Schaublin 136CNC |
|
Core Positioning |
Mass machining of precision shaft parts and small shell parts |
|
Number of Axes |
/ |
|
Key Accuracy |
Able to achieve 0.2μm roundness cutting, surface roughness up to Ra 0.05μm |
|
Core Configuration |
Machine tool temperature control system; adopt new Sauter turret with tool seat positioning accuracy ±1μm; precision C-axis accuracy up to 2 arc seconds |
|
Machining Capacity |
Able to perform hard material turning of HRC65 and titanium alloy machining |
|
Core Advantages |
High machining accuracy and excellent precision consistency of parts |
|
Typical Applications |
CNC Swiss precision machining, etc |
