Sanluo Precision's processing plant strictly controls the quality of eccentric turning CNC: clamping correction uses dial gauge to measure radial runout <0.01mm and axial runout <0.02mm to ensure clamping accuracy; eccentric detection uses two center pins measurement, micrometer to measure eccentricity with accuracy ±0.01mm, V-block to measure maximum and minimum diameters of eccentric shaft to calculate eccentricity, coordinate measuring machine to measure coordinates of two centers to calculate eccentricity and eccentric angle with accuracy ±0.003mm; dynamic balance eccentric parts have large centrifugal force during rotation and require dynamic balance with balance accuracy G6.3-G16 grade to reduce vibration; surface roughness Ra0.8-3.2μm with no chatter marks or tool marks, smooth surface; hardness detection after heat treatment with hardness HRC25-55, uniform hardness and normal structure.
|
Dimensional accuracy |
OD |
ID |
T（C） |
DP |
SH |
|
unit:±/mm |
0.002 |
0.002 |
0.005 |
0.002 |
0.005 |
|
Geometric accuracy |
Roundness |
Coaxiality |
Straightness |
Cylindricity |
Concentricity |
|
unit:±/mm |
0.002 |
0.003 |
0.002 |
0.003 |
0.002 |
|
Production capacity |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
1~999999 pcs |
|
Production cycle |
3-20 days |
3-20 days |
3-20 days |
3-20 days |
3-20 days |
As a professional manufacturer of eccentric turning CNC, Sanluo Precision serves various industries: automotive engines (crankshafts with eccentricity 30-80mm and multiple eccentricities, eccentricity accuracy of connecting rod journals and main journals ±0.02mm, dynamic balance grade G2.5; camshafts with cam lift 5-15mm, cam profile accuracy 0.05mm, surface quenching HRC50-55), compressors (eccentric shafts with eccentricity 5-30mm to drive piston reciprocating motion, accuracy ±0.015mm, surface Ra0.8μm; eccentric bushings with internal and external eccentricity, fit accuracy H7/h6), pumps and valves (eccentric rotors with eccentricity 2-20mm for fluid delivery through volume change, accuracy ±0.01mm; eccentric cams to control valve opening and closing with correct profile), textile machinery (eccentric wheels with eccentricity 10-50mm to drive shuttle reciprocating motion, accuracy ±0.02mm for stable high-speed operation; eccentric pins for eccentric adjustment of tension). We provide professional customized CNC lathe machining services for global customers.
|
Parameter Category |
Parameter Details |
|
Equipment model |
NLX 2500 |
|
Core Positioning |
High-flexibility and high-stability general-purpose turning, supporting heavy cutting |
|
Number of Axes |
4-axis |
|
Stroke (X/Y/Z) |
X-axis 260 mm / Y-axis ±60 mm / Z-axis 795 mm |
|
Machining Capacity |
Maximum turning diameter Ø366 mm, turning length 705 mm, bar specification Ø105 mm |
|
Spindle System |
Configurable with high-torque turnMASTER spindle, sub-spindle bar specification also Ø105 mm |
|
CNC System |
Configurable with Siemens SINUMERIK ONE or CELOS X version MAPPS system |
|
Core Advantages |
High-rigidity structure brings high precision; Y-axis supports power tool processing such as eccentric milling and drilling, with high flexibility |
|
Typical Applications |
precision eccentric turning CNC parts, etc |
|
Parameter Category |
Parameter Details |
|
Equipment model |
DS-30Y |
|
Core Positioning |
Powerful "all-in-one" turn-mill compound solution |
|
Number of Axes |
3-axis (with Y-axis and C-axis functions) |
|
Spindle System |
Dual spindles, spindle speed 4000 rpm, 4500 rpm |
|
Machining Capacity |
Maximum machining diameter 254 mm |
|
Turret System |
Standard 12-station BMT65 turret |
|
Y-axis Function |
Supports eccentric milling, drilling and tapping operations |
|
Core Advantages |
Opposing spindles support fully synchronous rotation, reducing cycle time; cost-effective |
|
Typical Applications |
precision eccentric turning CNC parts, etc |
