Machined Parts

Sanluo Precision is a professional manufacturer and supplier of machined parts in China. We have provided high-quality CNC machining parts services for customers for 18 years. The processing plant offers professional customized machining parts services for medical, semiconductor industry, scientific research, optical communication and other industries, supporting the customization of complex and difficult parts. From small shaft sleeves to large boxes, single piece or batch production fully meets customers' stringent requirements.

Send Inquiry

Product Description

Full-Category Parts Processing

Sanluo Precision’s processing plant provides full-category machined parts processing. Shaft parts: optical shaft, stepped shaft, hollow shaft, eccentric shaft, crankshaft, camshaft, diameter 5-500mm, length 10-3000mm, accuracy IT7-IT6 grade. Disc parts: flange, gear, pulley, cam, end cover, diameter φ20-800mm, thickness 5-200mm, gear accuracy 6-7 grade. Sleeve parts: shaft sleeve, bushing, coupling sleeve, sealing sleeve, inner diameter φ10-300mm, wall thickness 2-50mm, fit accuracy H6/H7. Box parts: pump body, valve body, gearbox, hydraulic block, size 100×100×100mm-1500×1000×800mm, hole system position tolerance 0.02-0.05mm.

Station Accuracy

Dimensional accuracy	L（X）	W（Y）	H（Z）	SH	SW
unit:±/mm	0.005	0.003	0.001	0.002	0.003
Geometric accuracy	Flatness	Parallelism	Perpendicularity	Roughness	Symmetry
unit:±/mm	0.001	0.002	0.002	Ra0.6	0.005
Production capacity	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs	1~999999 pcs
Production cycle	3-20 days	3-20 days	3-20 days	3-20 days	3-20 days

The configured testing instruments and measuring tools include: CMM coordinate measuring machine, image measuring instrument, projector, laser diameter gauge, laser interferometer, roughness meter, roundness meter, tool microscope, stereomicroscope, micrometer, pin gauge, dial indicator, 0.0001mm micrometer, electronic height gauge, caliper, gauge block, hardness tester, thread gauge.

Precision Processing Technology

As a professional manufacturer of machined parts, Sanluo Precision adopts advanced processing technology. Turning: CNC lathes and sliding head lathes process shaft parts, roundness 0.002mm, surface roughness Ra0.08-1.6μm. Heat treatment: quenching and tempering, quenching, carburizing and quenching, hardness HRC25-62 adjustable. Quality control: drawing review to determine processing difficulties, process planning to formulate the best route. First article inspection with full-size measurement by CMM, SPC process monitoring for mass production. 100% inspection for key dimensions, sampling inspection for general dimensions, special measuring tools for geometric tolerances. Coating thickness, hardness and adhesion inspection after surface treatment. Anti-rust cleaning before packaging to prevent bumps and scratches. Issue inspection reports and material certificates. We have provided customized machining parts services for well-known enterprises such as Sany Heavy Industry, Zoomlion and XCMG, with an annual output of over 2 million pieces and a pass rate of over 99.5%.

Technical Parameters of Machined Parts Equipment

Core Features:

Dual worktables, suitable for batch precision parts, high-rigidity structure + automatic pallet exchange, high efficiency, unmanned operation.

Category	Parameters
Mechanical Specifications	- X/Y/Z axis stroke: 300/200/200mm- Worktable size: 400×300mm- Max. load: 150kg- Spindle taper: HSK-A50
Processing Performance	- Spindle speed: 16000rpm (electric spindle)- X/Y/Z axis rapid traverse speed: 50m/min- Cutting feed speed: 1-15000mm/min- Tool magazine capacity: 15 tools (standard); 30 tools (optional)
Accuracy Index	- Positioning accuracy: ±0.002mm (full stroke)- Repeat positioning accuracy: ±0.001mm (full stroke)- Surface roughness: Ra≤0.1μm (aluminum parts)
Others	- CNC System: Makino Professional 6- Power: 20kW (spindle); 7.5kW (feed axis)- Features: Dual worktable exchange, supports 24-hour unmanned processing
Typical Applications	precision machined parts, etc

Core Features:

Small turn-mill compound processing machine, suitable for turning + milling compound processing of auto parts and precision parts (such as cylinder block, pulley), high-rigidity structure (suitable for heavy cutting).

Category	Parameters
Mechanical Specifications	- Stroke (X×Y×Z): 600×500×400mm- Spindle through-hole diameter: ø60mm- Worktable size: 800×500mm- Max. workpiece weight: 800kg
Processing Performance	- Spindle speed: 10000rpm (electric spindle)- Rapid traverse speed: 40m/min- Power tool torque: 72Nm- Tool magazine capacity: 20 tools (disc type)
Accuracy Index	- Positioning accuracy: ±0.004mm- Repeat positioning accuracy: ±0.002mm- Roundness accuracy: 0.4μm (full circle machining)
Others	- CNC System: Okuma OSP-P300- Power: 15kW (spindle); 7.5kW (feed axis)- Features: Supports sub-spindle (second spindle)
Typical Applications	precision machined parts, etc
